| 1 | Screw |
| 2 | Wall Holding Bracket |
| 3 | Primary External Arm |
| 4 | Round Rubber Motor Holder |
| 5 | 16 VCD Motor 5600 Rpm with Spur Gear Reducer |
| 6 | Rubber Gear Box Holder |
| 7 | Joint |
| 8 | Secondary External Arm |
| 9 | Coupler |
| 10 | Stainless Steel Coupler Ring |
| 11 | Bearing 6203-2RS |
| 12 | Metal Washer |
| 13 | Solid Steel Pin |
| 14 | Mechanical Screw |
| 15 | Screw Bearing |
| 16 | Circlip A12 |
| 17 | Screw Cover |
| 18 | Internal Arm |
| 19 | Door Holding Bracket |
| Supply Voltage | AC 110/ 220V, 60Hz / 50Hz |
| Backup Battery | 12V 7AH |
| Operating Voltage | Dc 16V for Normal Speed, DC 8V for Cushioning Speed |
| Max. Length of gate | 3.25 Meter per Wing |
| Safety Cluth | Electronic Current Sensing |
| Electronic Controller | Micro-Processor Based |
| Position Limit Device Temperature | Electronic Fuzzy Logic 0 to +80°C |
| Remote Controller | 2 Channels, 330MHz UHF |
| ราคา | โทรสอบถาม 02-052-1372, 086-0096905, 091-2244460, 092-8744458 |
